Airtac DPS Electronic Digital Display Pressure Sensor DPSP1B-01030
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPS Electronic Digital Pressure Sensor DPSP1B-01030 Technical Details
- Model: DPSP1B-01030
- Type: Digital display pressure sensor (electronic diaphragm type)
- Pressure range: -0.1~1.0 MPa (negative pressure to positive pressure measurement)
- Output signal: 4-20mA analog + RS485 digital output (Modbus RTU protocol)
- Power supply: 12-36VDC (±10% ripple)
- Accuracy: ±0.5% F.S. (25℃ reference)
- Display resolution: 0.001 MPa
- Operating temperature: -20℃ to 85℃ (no freezing)
- Storage temperature: -30℃ to 90℃
- Protection rating: IP67 (dust/water resistant)
- Electrical connection: M12-5pin aviation connector
- Process connection: G1/4" male thread (stainless steel 304)
- Weight: 280g ±5g (with packaging)
- Dimensions: 96mm(L) × 48mm(W) × 35mm(H) (body only)
- Response time: ≤10ms (90% step response)
- Media compatibility: Clean dry air, non-corrosive gases
- Long-term stability: ≤±0.3% F.S./year
- Certifications: CE, RoHS, EMC Directive 2014/30/EU
High-visibility OLED display with 360° rotation capability features auto power-off function (configurable). The dual-output design enables simultaneous analog signal transmission and digital communication. Shock-resistant aluminum alloy housing with anti-vibration mounting design (3-axis damping structure). Includes built-in temperature compensation and overload protection up to 150% FS.
- Real-time pressure monitoring in pneumatic conveyor systems
- Hydraulic press pressure feedback control
- HVAC duct static pressure measurement
- CNC machine tool lubrication pressure detection
- Plastic injection molding machine pressure regulation
- Industrial IoT predictive maintenance systems
Installation guidelines:
Mount in vibration-free locations using included isolation bracket.
Maintain 50mm clearance around display for visibility.
Apply thread sealant (PTFE tape) on process connection.
Perform zero calibration after 24hrs of continuous operation.
| Property | Property Value |
|---|---|
| sku | DPSP1B-01030 |
