Airtac DS1E Electronic Sensor DS1E050
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E050 Electronic Proximity Sensor Technical Details
- Model: DS1E050
- Type: Inductive proximity sensor (Shielded)
- Sensing distance: 5mm ±10%
- Output configuration: NPN Normally Open (NO)
- Supply voltage: 10-30V DC
- Current consumption: ≤15mA
- Operating temperature: -25℃ to 70℃
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass with ABS cover
- Connection: 2m PVC cable (M8 connector optional)
- Response time: ≤1ms
- Repeat accuracy: ±0.2mm
- Hysteresis: ≤15% of sensing distance
- Surge protection: Reverse polarity & overload protection
- Weight: 80g ±5%
- Dimensions: 50mm(L) × 25mm(W) × 15mm(H)
High-precision non-contact detection sensor featuring temperature compensation circuitry for stable performance in fluctuating environments. The stainless steel sensing face resists mechanical wear and chemical corrosion, while the IP67 rating ensures reliable operation in dusty or humid conditions. Includes status LED for real-time monitoring.
- Position verification in CNC machine tool changers
- Metal part counting in automotive assembly lines
- Pallet presence detection in logistics conveyors
- Safety interlock systems for industrial robots
- End-of-stroke detection in pneumatic cylinders
Installation guidance:
Maintain 2x sensor diameter clearance from adjacent metal surfaces (minimum 10mm).
For maximum accuracy, calibrate after installation using the teach-in function.
| Property | Property Value |
|---|---|
| sku | DS1E050 |
