Airtac DS1E Electronic Sensor DS1EC08
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Electronic Sensor DS1EC08 Technical Specifications
- Model: DS1EC08
- Sensor type: Inductive proximity sensor (shielded)
- Detection distance: 8mm ±10%
- Operating voltage: DC 10-30V (±10% ripple)
- Output configuration: NPN/PNP selectable (3-wire)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Inductor head material: PBT+PC composite
- Temperature range: -25℃ to +70℃ (storage: -40℃ to +85℃)
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Shock resistance: 1000m/s² (3-axes)
- Cable length: 2m standard (PUR jacket)
- Connector type: M8 3-pin quick disconnect
- Weight: 98g ±2g
- Dimensions: 34mm(L) × 18mm(W) × 10mm(H)
High-precision inductive sensor with temperature compensation circuit, featuring automatic protection against short-circuit and reverse polarity. The triple-sealed structure with O-ring provides exceptional dust/water resistance. Dual-color LED indicates power status (green) and detection state (orange).
- Position verification in CNC machine tooling
- Automated palletizing system object detection
- Hydraulic cylinder end position sensing
- Conveyor belt metal object counting
- Robotic arm joint limit detection
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For flush mounting applications, ensure target object exceeds
1.5× sensing distance. Clean sensing face weekly with isopropyl alcohol.
