Airtac DS1E Electronic Sensor DS1EN050
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Electronic Proximity Sensor DS1EN050 Technical Details
- Model: DS1EN050
- Type: Shielded inductive proximity sensor (electronic)
- Sensing distance: 0.5mm ±10%
- Output configuration: NPN normally open (NO)
- Supply voltage: 10-30V DC
- Current consumption: ≤15mA
- Response time: ≤0.5ms
- Hysteresis: ≤10% of sensing distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (Fe≥12x12mm)
- Temperature range: -25℃ to +70℃
- Connection type: 3-wire M8x1 quick-disconnect
- Cable length: Standard 2m (customizable)
- EMC protection: 30V/m (IEC 60947-5-2)
- Weight: 80g ±5%
- Dimensions: 18mm(D) × 34mm(L) × 10mm(W)
High-precision shielded inductive sensor with temperature compensation circuitry, designed for micron-level position detection in harsh industrial environments. Features reverse polarity protection and short-circuit prevention. The anodized aluminum face provides chemical resistance against cutting fluids and coolants.
- Robotic arm end effector positioning
- High-speed packaging machine jam detection
- CNC tooling limit switches
- Semiconductor wafer handling systems
- Automated warehouse stacker position verification
Installation guidelines:
Maintain 0.8x sensing distance between sensor face and target.
Avoid mounting near high-frequency equipment (>50kHz).
For optimal performance, clean sensing surface monthly with IPA wipes.
