Airtac DS1E Electronic Sensor DS1EP020
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Electronic Sensor DS1EP020 Technical Specifications
- Model: DS1EP020
- Type: Inductive proximity sensor (Embedded installation)
- Detection principle: Electromagnetic induction
- Output configuration: NPN/PNP NO/NC selectable
- Supply voltage: 10-30V DC (±10%)
- Current consumption: ≤15mA
- Detection distance: 2mm ±10% (Iron target)
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC 60529)
- Temperature range: -25℃ to +70℃
- Housing material: Nickel-plated brass
- Connection type: 2m PVC shielded cable (M12 connector optional)
- Weight: 120g ±5g
- Dimensions: 18mm(D) × 34mm(L) × 10mm(H)
High-precision non-contact sensor with temperature compensation circuitry, featuring exceptional stability in fluctuating environments. The anti-electromagnetic interference design ensures reliable operation near VFDs and motors. Integrated reverse polarity protection prevents installation errors.
- Position verification in CNC machine tool changers
- Sheet metal counting in stamping presses
- End-of-stroke detection in pneumatic cylinders
- Rotational speed monitoring on conveyor rollers
- Pallet presence checking in AS/RS warehouses
Installation guidelines:
Maintain 3x sensor diameter clearance from adjacent metal surfaces.
For flush mounting applications, use M18x1 mounting nut (sold separately).
Perform teach-in procedure after installation using the calibration button.
| Property | Property Value |
|---|---|
| sku | DS1EP020 |
