Airtac DS1E Electronic Sensor DS1EP050
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Electronic Inductive Proximity Sensor DS1EP050 Technical Details
- Model: DS1EP050
- Sensor type: Inductive DC 3-wire NPN/PNP
- Detection distance: 5mm ±10% (Standard metal target)
- Output configuration: Normally open (NO) / Normally closed (NC) selectable
- Supply voltage: 10-30V DC (±10% ripple)
- Output current: ≤200mA (Resistive load)
- Response frequency: 1kHz (Iron target at 5mm)
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass (Detection face: PBT plastic)
- Connection type: 2m PVC cable (M12x1 connector optional)
- Ambient temperature: -25℃ to +70℃ (No icing)
- Vibration resistance: 10-55Hz with 1.5mm amplitude
- Shock resistance: 1000m/s² (3-axes)
- Weight: 78g ±3g (With cable)
- Dimensions: 34mm(L) × 18mm(W) × 10mm(H) (Cylindrical housing)
High-precision industrial proximity sensor featuring temperature compensation circuitry and reverse polarity protection. The DS1EP050's corrosion-resistant construction enables reliable metal object detection in harsh environments, with LED status indication for operational feedback. Features ±15% voltage tolerance and short-circuit protection.
- Position verification in CNC machine tool changers
- Conveyor belt part counting systems
- Hydraulic cylinder end-position detection
- Automated packaging machine safety interlocks
- Robotic arm tooling presence confirmation
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance, align target approach perpendicular to sensing face.
Use shielded cable in high EMI environments.
| Property | Property Value |
|---|---|
| sku | DS1EP050 |
Returns will be accepted for up to 15 days of Customer’s receipt or tracking number on Not used items. You, as a Customer, are obliged to inform us via email before you return the item, only in the case of:
- Received the wrong item.
- Item arrived not as expected (ie. damaged packaging).
- Item had defects.
- Over delivery time.
- The shipper does not allow the goods to be inspected before payment.
The returned product(s) must be in the original packaging, safety wrapped, undamaged and unworn. This means that the item(s) must be safely packed in a carton box for protection during transport, possibly the same carton used to ship to you as a customer.
