Airtac DS1E Electronic Sensor DS1EPC08
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Electronic Sensor DS1EPC08 Technical Specifications
- Model: DS1EPC08
- Sensor Type: Inductive proximity sensor (Embedded cylindrical)
- Detection Principle: Electromagnetic induction (non-contact)
- Detection Distance: 8mm ±10% (Sn: 8mm)
- Output Configuration: PNP NO (Normally Open) / NC (Normally Closed) selectable
- Supply Voltage: 10-30V DC (±10% ripple)
- Current Consumption: ≤15mA
- Output Current: ≤200mA
- Response Frequency: 1kHz
- Hysteresis: ≤10% of detection distance
- Protection Rating: IP67 (IEC standard)
- Housing Material: Nickel-plated brass with PBT sensing face
- Operating Temperature: -25℃ to +70℃
- Storage Temperature: -40℃ to +85℃
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude
- Shock Resistance: 500m/s² (approx. 50G), 3 axes
- Weight: 120g ±5%
- Dimensions: Ø18mm × 60mm(L) (M18×1 threaded barrel)
High-precision industrial-grade proximity sensor featuring temperature compensation circuitry for stable detection in fluctuating environments. The DS1EPC08's rugged brass construction withstands mechanical stress and chemical exposure, while its IP67 rating ensures reliable operation in wet/dusty conditions. Requires shielded cabling for EMI-sensitive applications.
- Position verification in CNC machine tool changers
- Pallet presence detection in automated warehouses
- End-of-stroke confirmation in hydraulic cylinders
- Rotary encoder synchronization in packaging lines
- Safety interlock systems for robotic workcells
Installation guidelines:
Maintain 2×Sn clearance between adjacent sensors (16mm minimum).
For metallic backgrounds, use 3×Sn distance or install non-ferrous spacers.
Clockwise rotation during mounting prevents cable twisting.
| Property | Property Value |
|---|---|
| sku | DS1EPC08 |
