Airtac DS1E Electronic Sensor DS1EPC12
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Inductive Proximity Sensor DS1EPC12 Technical Details
- Model: DS1EPC12
- Type: Shielded cylindrical inductive sensor (NO)
- Sensing distance: 2mm ±10%
- Output configuration: NPN normally open (3-wire)
- Supply voltage: 10-30VDC (±10% ripple)
- Current consumption: ≤15mA (no load)
- Output current: ≤200mA (short-circuit protected)
- Response frequency: 1kHz (iron target)
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (IEC 60529)
- Housing material: Nickel-plated brass
- Sensing face: Reinforced PBT polymer
- Operating temperature: -25℃ to +70℃
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3-axes)
- Cable: 2m PVC jacket (optional 5m available)
- Weight: 82g (sensor body only)
- Dimensions: Ø18mm × 34mm (L1=12mm thread length)
High-precision industrial-grade proximity detector with embedded reverse polarity protection and overload prevention. Features a red LED status indicator and zero-speed detection capability. Optimized for metallic object recognition in high-vibration environments with ±3% repeatability tolerance.
- CNC machine tool position feedback
- Conveyor belt object counting systems
- Robotic arm end-effector alignment
- Hydraulic cylinder piston position verification
- Packaging machine safety interlocks
Installation guidelines:
Maintain 2x sensor diameter clearance from adjacent metal surfaces.
Use M18×1 mounting nut (included) with 0.8-1.5Nm torque.
Clean sensing face weekly with isopropyl alcohol in dusty environments.
| Property | Property Value |
|---|---|
| sku | DS1EPC12 |
