Airtac DS1F Electronic Sensor DS1F020
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F Electronic Sensor DS1F020 Technical Specifications
- Model: DS1F020
- Sensor type: Inductive proximity sensor (NPN/PNP output optional)
- Detection distance: 2mm ±10%
- Target material: Ferrous metals (Fe), non-ferrous metals (Cu, Al)
- Supply voltage: 10-30V DC ±10% (ripple P-P ≤10%)
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3 axes)
- Weight: 52g ±2g
- Dimensions: 34mm(L) × 18mm(W) × 10mm(H)
- Connection: 2m PVC cable / M8 connector (customizable)
- LED status indicator: Power/operation display
High-precision industrial-grade proximity sensor featuring temperature compensation circuitry for stable detection in varying environments. The triple-shielded design prevents mutual interference in dense installations. With reverse polarity protection and short-circuit prevention, it's built for 24/7 operation in harsh conditions.
- Position verification in CNC machine tool changers
- Sheet metal counting in stamping machines
- End-of-stroke detection in hydraulic cylinders
- Conveyor belt object presence monitoring
- Robotic arm position feedback systems
Installation guidelines:
Maintain 3x sensor diameter clearance between adjacent units (≥54mm).
For side-by-side mounting, stagger sensors by 45° to prevent mutual interference.
Use copper shielding when installed near high-frequency equipment.
| Property | Property Value |
|---|---|
| sku | DS1F020 |
