Airtac DS1F Electronic Sensor DS1F030
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F030 Electronic Inductive Proximity Sensor Technical Details
- Model: DS1F030
- Sensor type: Shielded inductive proximity sensor
- Detection principle: Electromagnetic induction
- Output configuration: NPN normally open (NO)
- Supply voltage: 10-30V DC (±10% ripple)
- Current consumption: ≤15mA
- Detection distance: 3mm ±10% (Iron target)
- Repeat accuracy: ≤0.1mm
- Response frequency: 500Hz
- Hysteresis: 1-20% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +70℃
- Storage temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Shock resistance: 100m/s² (3 times each axis)
- Connection: 2m PVC cable (standard), M12 connector optional
- Weight: 100g ±5% (sensor body only)
- Dimensions: 50mm(L) × 25mm(W) × 15mm(H)
High-precision non-contact sensor with temperature compensation circuitry, designed for industrial automation environments. Features reverse polarity protection and short-circuit prevention. The shielded design minimizes electromagnetic interference while allowing flush mounting in metal surfaces.
- Position verification in CNC machine tool changers
- Object detection in conveyor belt systems
- End-of-stroke detection in pneumatic cylinders
- Rotational speed monitoring in motor shafts
- Part presence verification in assembly robots
Installation guidelines:
Maintain 2× sensor diameter clearance between adjacent units.
For metallic environments, use 0.5-1mm air gap when flush mounting.
Clean sensing face regularly using isopropyl alcohol.
| Property | Property Value |
|---|---|
| sku | DS1F030 |
