Airtac DS1F Electronic Sensor DS1FC08
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F Electronic Sensor DS1FC08 Technical Details
- Model: DS1FC08
- Type: Rectangular DC 3-wire inductive proximity sensor
- Sensing distance: 0.8mm ±10% (Embedded flush-mount)
- Output configuration: NPN/PNP NO/NC selectable
- Supply voltage: 10-30V DC (±10% ripple)
- Current consumption: ≤15mA (No load)
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (IEC60529)
- Housing material: Nickel-plated brass
- Temperature range: -25℃ to +70℃ (Operation), -40℃ to +85℃ (Storage)
- Connection type: 2m PVC cable (Standard), M8 connector optional
- Cable specification: 3-core, 0.2mm², Ø4.5mm
- Installation: Non-flush mounting (shielded)
- Weight: 120g ±5%
- Dimensions: 18mm(W) × 18mm(D) × 40mm(L)
High-precision inductive sensor with temperature-stable oscillation circuit, featuring reverse polarity protection and short-circuit prevention. The copper-zinc alloy housing provides exceptional resistance to mechanical stress and chemical corrosion. Includes status LED for operational feedback.
- Position verification in CNC machine tool changers
- Sheet metal detection in stamping presses
- End-of-stroke detection in pneumatic cylinders
- Conveyor belt object counting systems
- Robotic arm joint limit sensing
Installation guidance:
Maintain minimum 3x sensor diameter spacing between adjacent units.
For metallic backgrounds, ensure ≥3mm air gap behind mounting surface.
| Property | Property Value |
|---|---|
| sku | DS1FC08 |
