Airtac DS1F Electronic Sensor DS1FN030
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F Electronic Sensor DS1FN030 Technical Details
- Model: DS1FN030
- Type: Rectangular DC 3-wire inductive proximity sensor
- Detection distance: 3mm ±10% (Non-adjustable)
- Output configuration: NPN normally open (NO)
- Supply voltage: 10-30V DC (±10% ripple)
- Current consumption: ≤15mA (No load)
- Output current: ≤200mA (Short-circuit protected)
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Sensor face: PBT resin
- Temperature range: -25℃ to +70℃ (Operation), -40℃ to +85℃ (Storage)
- Connection type: 2m PVC cable (3-core 0.2mm²) with IP67-rated gland
- Weight: 85g ±5% (Excluding cable)
- Dimensions: 34mm(W) × 10mm(H) × 6.5mm(D)
High-precision non-contact detection sensor featuring reverse polarity protection and surge suppression. The shielded design minimizes mutual interference in multi-sensor arrays. Copper-alloy housing provides EMI resistance in industrial environments. Requires metallic targets ≥Fe360 (equivalent to Q235 steel) for optimal performance.
- Position verification in pneumatic cylinder end stops
- Object presence detection on conveyor systems
- Rotary encoder synchronization in packaging machinery
- Safety interlock systems for machine guarding
- Component counting in automated assembly lines
Installation guidelines:
Maintain 2× sensor width clearance between adjacent units. For flush mounting,
ensure target approaches perpendicular to sensing face. Clean ferrous debris
monthly using isopropyl alcohol wipes.
| Property | Property Value |
|---|---|
| sku | DS1FN030 |
