Airtac DS1F Electronic Sensor DS1FN050
2. The device typically comprises four core components: temperature sensing probe, signal processing unit, digital display interface, and power supply system.
3. As the sensitive component, the temperature probe employs single or multiple high-precision fast-response thermistors, which critically determine both temperature measurement accuracy (typical tolerance ±0.5°C) and rapid response characteristics (≤200ms).
AirTAC DS1F Electronic Sensor DS1FN050 Technical Details
- Model: DS1FN050 (Inductive Proximity Sensor)
- Detection distance: 5mm ±10%
- Operating voltage: DC 12-24V (±10% ripple)
- Output type: NPN NO (Normally Open) / PNP NO (configurable)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Temperature range: -25℃ to +70℃
- Housing material: Nickel-plated brass
- Indication: LED status light (red)
- Cable length: 2m standard (PVC shielded cable)
- Weight: 210g ±5g
- Dimensions: 48mm(L) × 18mm(W) × 36mm(H)
High-precision non-contact sensor with temperature compensation circuit, designed for harsh industrial environments. Features reverse polarity protection and short-circuit prevention. The shielded construction minimizes electromagnetic interference, making it suitable for CNC machinery applications.
- Position detection in pneumatic cylinder systems
- Conveyor belt object counting systems
- Automated assembly line quality control
- Robotic arm end effector alignment
- Packaging machine safety interlocks
Installation guidelines:
Maintain 2× sensor diameter clearance from metal surfaces. For optimal performance,
align target metal face perpendicular to sensor axis. Use M18×1 mounting nut with
10-15N·m torque. Regular cleaning with isopropyl alcohol recommended in dusty environments.
| Property | Property Value |
|---|---|
| sku | DS1FN050 |
