Airtac DS1GP Electronic Sensor DS1GP020
2. Its architecture comprises four core components: thermometric probe, signal processing unit, digital display interface, and stabilized power supply system.
3. The thermometric probe utilizes one or multiple high-precision, rapid-response thermistors as sensing elements, critically determining both output temperature accuracy and thermal response speed characteristics.
AirTAC DS1GP Electronic Sensor DS1GP020 Technical Details
- Model: DS1GP020
- Type: Inductive proximity sensor (DC 3-wire)
- Detection distance: 2mm ±10%
- Output configuration: NPN NO/NC or PNP NO/NC (selectable)
- Supply voltage: 10-30V DC (±10% ripple)
- Current consumption: ≤15mA
- Response frequency: 1kHz (metal target)
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC 60529)
- Housing material: Nickel-plated brass with PTFE sensing face
- Operating temperature: -25℃ to +70℃
- Storage temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Shock resistance: 1000m/s² (3 axes)
- Weight: 85g ±3g
- Dimensions: 25mm(W) × 15mm(D) × 40mm(H)
- Cable specification: 2m PVC cable, 4-core shielded (0.2mm²)
- LED status indicator: Power/Output dual display
High-precision non-contact sensor with anti-corrosion design, featuring temperature compensation circuitry for stable detection in fluctuating environments. The PTFE-coated sensing face provides exceptional resistance to welding spatter and chemical exposure. Equipped with reverse polarity protection and short-circuit prevention.
- Position verification in pneumatic cylinder end stops
- Metal part counting in assembly conveyor systems
- Machine tool safety interlocks
- Liquid level detection in metal containers
- Robotic arm end effector positioning
- Packaging machine jam detection
Installation guidelines:
Maintain ≥3mm clearance from adjacent metal surfaces. For optimal performance,
align target perpendicular to sensor face within ±5° tolerance. Use M12×1 mounting
nut with 10-15N·m torque. Avoid installing near high-frequency welding equipment.
| Property | Property Value |
|---|---|
| sku | DS1GP020 |
