Airtac DS1GP Electronic Sensor DS1GP030
2. Its architecture comprises four core components: thermometric probe, signal processing unit, digital display interface, and stabilized power supply system.
3. The thermometric probe utilizes one or multiple high-precision, rapid-response thermistors as sensing elements, critically determining both output temperature accuracy and thermal response speed characteristics.
AirTAC DS1GP030 Inductive Proximity Sensor Specifications
- Model: DS1GP030
- Type: DC 3-wire inductive proximity sensor (shielded)
- Detection distance: 3mm ±10% (adjustable via built-in potentiometer)
- Output configuration: NPN NO (Normally Open) / PNP NO selectable
- Supply voltage: 10-30V DC (ripple ≤10%)
- Current consumption: ≤15mA
- Hysteresis: ≤15% of detection distance
- Response frequency: 500Hz
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass with PBT sensing face
- Cable: 2m PUR cable (customizable 1-10m options)
- Repeat accuracy: ±0.1mm
- Ambient temperature: -25℃ to +70℃ (non-freezing)
- Weight: 68g ±2g (excluding cable)
- Dimensions: Ø12mm × 34mm (L) × 4mm thread protrusion
- Mounting: M12×1 flush installation (requires 0.5mm alignment tolerance)
High-precision industrial proximity sensor featuring temperature compensation and reverse polarity protection. The DS1GP030's anti-interference design enables stable metal detection in high-vibration environments. Includes status LED with selectable modes (always-on/pulse/off). Meets EMC Directive 2014/30/EU requirements.
- CNC machine tool position feedback
- Automated conveyor belt object counting
- Robotic arm end effector alignment
- Hydraulic cylinder piston position verification
- Packaging machine cap detection
Installation guidelines:
Maintain 3× sensor diameter clearance (≥36mm) from adjacent metal surfaces.
For optimal performance, clean sensing face weekly with isopropyl alcohol.
Use shielded conduit when running parallel with high-voltage cables (>200V AC).
| Property | Property Value |
|---|---|
| sku | DS1GP030 |
