Airtac DS1GP Electronic Sensor DS1GP050
2. Its architecture comprises four core components: thermometric probe, signal processing unit, digital display interface, and stabilized power supply system.
3. The thermometric probe utilizes one or multiple high-precision, rapid-response thermistors as sensing elements, critically determining both output temperature accuracy and thermal response speed characteristics.
AirTAC DS1GP050 Electronic Proximity Sensor Specifications
- Model: DS1GP050
- Type: Inductive proximity sensor (shielded)
- Sensing distance: 5mm ±10%
- Output configuration: NPN/PNP NO/NC selectable
- Supply voltage: DC 10-30V (ripple ≤10%)
- Output current: ≤200mA
- Hysteresis: ≤15% of sensing distance
- Response frequency: 1kHz
- Protection rating: IP67 (IEC 60529)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (Fe≥99.5%)
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3 axes)
- Connection: 2m PVC cable (standard), M12 connector optional
- Weight: 85g ±3g
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H)
- Certifications: CE, RoHS, REACH
High-precision industrial-grade proximity sensor featuring temperature compensation circuitry for stable detection in fluctuating environments. The corrosion-resistant housing and triple-sealed structure (epoxy resin + O-ring + cable gland) ensure reliable operation in harsh conditions including oil mist and particulate exposure.
- Position verification in CNC machine tool changers
- Sheet metal counting in stamping presses
- End-of-stroke detection in pneumatic cylinders
- Conveyor belt object presence monitoring
- Robotic arm tooling alignment systems
Installation guidelines:
Maintain 2×sensing distance between adjacent sensors (≥10mm spacing).
For metallic backgrounds, use 3×sensing distance clearance (≥15mm).
Regularly clean sensing face with isopropyl alcohol to prevent false triggers.
- NPN-NO: Sinking output for PLC input modules
- NPN-NC: Fail-safe detection circuits
- PNP-NO: 3-wire positive logic systems
- PNP-NC: High-level signal interruption detection
