Airtac DS1GP Electronic Sensor DS1GPC08
2. Its architecture comprises four core components: thermometric probe, signal processing unit, digital display interface, and stabilized power supply system.
3. The thermometric probe utilizes one or multiple high-precision, rapid-response thermistors as sensing elements, critically determining both output temperature accuracy and thermal response speed characteristics.
AirTAC DS1GP Electronic Proximity Sensor DS1GPC08 Technical Specifications
- Model: DS1GPC08 (DS1GP series)
- Sensor type: Inductive proximity sensor
- Power supply: 10-30V DC (±10% ripple)
- Output configuration: PNP normally open (NO)
- Detection distance: 2mm ±10% (Iron target)
- Output current: ≤200mA
- Operating temperature: -25℃ to +70℃
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Connection type: 2m PVC cable (M8 connector optional)
- Response frequency: 500Hz
- Hysteresis: ≤15% of detection distance
- Weight: 68g ±3g
- Dimensions: 18mm(D) × 34mm(L) × 8mm(H) (Cylindrical body)
- LED indicator: Red (Power/Status)
- Surge protection: Reverse polarity protection & short-circuit protection
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
High-precision cylindrical inductive sensor with temperature-compensated circuitry, featuring enhanced EMI/RFI immunity for industrial environments. The stainless steel sensing face resists oil contamination and mechanical impacts. Automatic output current limitation prevents damage from overload conditions.
- Position verification in CNC machine tool changers
- Metal part detection on conveyor sorting systems
- End-of-stroke detection in hydraulic cylinders
- Presence sensing in automated packaging lines
- Safety interlock systems for robotic workcells
Installation guidelines:
Maintain 1.5x sensor diameter clearance from adjacent metal surfaces.
For optimal performance in high-vibration environments, use M12 locknut
(included) with 12-15 N·m torque. Clean sensing face weekly in dusty conditions.
| Property | Property Value |
|---|---|
| sku | DS1GPC08 |
