Airtac DS1GP Electronic Sensor DS1GPC12
2. Its architecture comprises four core components: thermometric probe, signal processing unit, digital display interface, and stabilized power supply system.
3. The thermometric probe utilizes one or multiple high-precision, rapid-response thermistors as sensing elements, critically determining both output temperature accuracy and thermal response speed characteristics.
AirTAC DS1GP-C12 Electronic Proximity Sensor Technical Details
- Model: DS1GPC12
- Type: Inductive proximity sensor (shielded)
- Sensing distance: 2mm ±10%
- Output configuration: NPN/PNP dual-mode selectable
- Supply voltage: 10-30VDC (±10% ripple)
- Current consumption: ≤15mA
- Response frequency: 1kHz (max)
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (IEC 60529)
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Housing material: Nickel-plated brass with PTFE sensing face
- Cable specification: 2m PUR cable (optional 5m/10m variants)
- Connection: M12 × 1 4-pin quick-disconnect
- Weight: 112g ±3g
- Dimensions: Ø18mm × 60mm (L)
- Certifications: CE, RoHS, REACH
High-precision industrial-grade sensor featuring temperature-compensated oscillation circuitry for stable detection of metallic targets. The dual-color LED (red/green) provides clear status indication through transparent housing. Built-in reverse polarity and surge protection (1.5kV) ensures reliability in harsh electrical environments.
- Position verification in CNC tool changers
- End-of-stroke detection for pneumatic cylinders
- Conveyor belt object counting systems
- Robotic arm joint limit sensing
- Hydraulic press safety interlocks
Installation guidelines:
Maintain 3× sensor diameter clearance from adjacent metal surfaces (≥54mm).
For threaded mounting, use 18mm open-end wrench with 10-15N·m torque.
Clean sensing face weekly using isopropyl alcohol in dusty environments.
| Property | Property Value |
|---|---|
| sku | DS1GPC12 |
