Airtac DS1H Electronic Sensor DS1HLN030
2. Its architecture typically integrates four key components: a temperature sensing probe, signal processing unit, LCD display module, and regulated power supply system.
3. Employing high-precision, fast-response thermistors as its core sensing component, the probe's design directly determines measurement accuracy (±0.5% F.S. typical) and achieves response times under 100ms in standard operating conditions.
AirTAC DS1H Electronic Sensor DS1HLN030 Technical Details
- Full model: DS1HLN030
- Sensor type: Rectangular inductive proximity sensor
- Detection distance: 30mm ±10% (Sn)
- Output configuration: NPN normally open (NO)
- Supply voltage: 10-30V DC (ripple ≤10%)
- Output current: ≤200mA
- Protection rating: IP67 (dust/water resistant)
- Housing material: Nickel-plated brass with PBT sensing face
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Connection type: 2m PVC cable (standard) with brown/blue/black wires
- Response time: ≤1ms
- Cable specifications: 0.34mm² × 3-core, oil-resistant
- Weight: Approximately 120g
- Dimensions: 30mm(W) × 18mm(D) × 50mm(H)
High-precision industrial proximity sensor featuring temperature compensation circuitry for stable detection in fluctuating environments. The triple-shielded design minimizes electromagnetic interference, with LED status indication for operational feedback. Compatible with ISO 9001/TS16949 standards.
- Position verification in automated assembly lines
- Pallet presence detection in logistics sorting systems
- Safety interlock monitoring for machinery guards
- Liquid level sensing in food packaging equipment
- Conveyor belt object counting applications
Installation guidelines:
Maintain 2×Sn distance from adjacent metal surfaces. For optimal performance,
clean sensing face weekly with isopropyl alcohol in dusty environments.
Avoid installation near high-frequency welding equipment.
| Property | Property Value |
|---|---|
| sku | DS1HLN030 |
