Airtac DS1H Electronic Sensor DS1HN020
2. Its architecture typically integrates four key components: a temperature sensing probe, signal processing unit, LCD display module, and regulated power supply system.
3. Employing high-precision, fast-response thermistors as its core sensing component, the probe's design directly determines measurement accuracy (±0.5% F.S. typical) and achieves response times under 100ms in standard operating conditions.
AirTAC DS1H Electronic Sensor DS1HN020 Technical Specifications
- Model: DS1HN020
- Type: Rectangular DC 3-wire inductive proximity sensor
- Sensing distance: 2mm ±10% (Sn)
- Supply voltage: 10-30V DC
- Output type: NPN/PNP selectable (NO+NC configurable)
- Current consumption: ≤13mA
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (Fe≥12mm³)
- Temperature range: -25℃ to +70℃
- Response frequency: 1kHz
- Connection type: 2m PVC cable (M8 connector optional)
- Installation: Flush/non-flush mountable
- Weight: 85g ±3g
- Dimensions: 18mm(W) × 34mm(L) × 10mm(H)
High-precision inductive sensor with dual output configuration and environmental resistance. Features reverse polarity protection and short-circuit prevention. The stainless steel sensing face provides enhanced durability in harsh conditions. Compatible with PLC input modules through selectable NPN/PNP switching.
- Position verification in automotive assembly lines
- Metal part detection in food packaging machinery
- End-of-stroke sensing for pneumatic cylinders
- Collision detection in collaborative robots
- Conveyor belt object counting systems
Installation guidelines:
Maintain 3×Sn distance between multiple sensors. For non-ferrous metal environments,
reduce rated sensing distance by 15%. Use shielded cables when operating near frequency converters.
| Property | Property Value |
|---|---|
| sku | DS1HN020 |
