Airtac DS1H Electronic Sensor DS1HNC08
2. Its architecture typically integrates four key components: a temperature sensing probe, signal processing unit, LCD display module, and regulated power supply system.
3. Employing high-precision, fast-response thermistors as its core sensing component, the probe's design directly determines measurement accuracy (±0.5% F.S. typical) and achieves response times under 100ms in standard operating conditions.
AirTAC DS1HNC08 Electronic Proximity Sensor Specifications
- Model: DS1HNC08
- Type: Non-contact inductive proximity sensor (Normally Closed)
- Sensing distance: 8mm ±10%
- Output configuration: NPN/PNP selectable (3-wire)
- Operating voltage: 10-30VDC (±10% ripple)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (≥Fe360)
- Temperature range: -25℃ to +70℃ (storage: -40℃ to +85℃)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3-axis)
- Weight: 85g ±2%
- Dimensions: Ø18mm × 60mm (L) × M12 threaded barrel
- Cable length: 2m standard (shielded 4-core 0.34mm²)
High-precision industrial proximity sensor with temperature-stabilized oscillation circuit, featuring automatic compensation for voltage fluctuations and electromagnetic interference. The hardened stainless steel face provides collision resistance in harsh environments. Dual-color LED indicates power (green) and output status (orange).
- Position verification in CNC machine tool changers
- Pallet presence detection in automated warehouses
- Safety interlock systems for robotic workcells
- Sheet metal counting in stamping presses
- Conveyor belt jam detection
Installation guidelines:
Maintain 2× sensing distance between adjacent sensors. For flush mounting,
ensure metallic surroundings are grounded. Use anti-rotation brackets
in high-vibration applications. Calibrate after installation using
the built-in sensitivity potentiometer.
| Property | Property Value |
|---|---|
| sku | DS1HNC08 |
