Airtac DS1U Electronic Sensor DS1U020
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Electronic Sensor DS1U020 Technical Specifications
- Model: DS1U020
- Type: Rectangular DC 3-wire inductive proximity sensor
- Detection distance: 2.0mm ±10% (Fe target)
- Supply voltage: 10-30V DC (ripple ≤10% P-P)
- Output configuration: NPN NO (Normally Open) or PNP NO selectable
- Housing material: Nickel-plated brass with PBT sensing face
- Protection rating: IP67 (IEC 60529)
- Temperature range: -25℃ to +70℃ (non-freezing)
- Response frequency: 1kHz (1ms ON/OFF response)
- Connection: 2m PVC cable (standard) / M12 connector (optional)
- Cable specs: 4-core 0.2mm² (28AWG) with oil-resistant jacket
- Indication: Red LED status indicator
- Hysteresis: ≤15% of detection distance
- Voltage drop: ≤2.5V @ 200mA
- Weight: 85g ±3g
- Dimensions: 50mm(L) × 18mm(W) × 34mm(H)
High-precision non-contact sensor with temperature compensation circuit, featuring reverse polarity protection and short-circuit prevention. The triple-shielded design provides exceptional EMI resistance (100mA/m @ 10MHz-1GHz). Precision-machined threads (M18×1) enable micrometer-level adjustment during installation.
- Position verification in pneumatic cylinder end stops
- Rotary encoder synchronization in packaging machinery
- Tool presence detection in CNC automatic changers
- Conveyor belt object counting systems
- Safety interlock for food processing equipment guards
Installation guidelines:
Maintain 3× sensor diameter clearance from adjacent metal surfaces.
For side-by-side mounting, minimum 20mm spacing between sensors.
Use copper-shielded cable in high frequency interference environments.
- Withstands 1000Hz vibration (10-55Hz, 1.5mm amplitude)
- 50g shock resistance (11ms duration, IEC 60068-2-27)
- Operates at 95% RH non-condensing
| Property | Property Value |
|---|---|
| sku | DS1U020 |
