Airtac DS1U Electronic Sensor DS1U030
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Electronic Sensor DS1U030 Technical Specifications
- Model: DS1U030
- Type: Non-contact inductive proximity sensor
- Sensing distance: 3mm ±10% (Embedded flush-mount type)
- Supply voltage: 10-30V DC (±10% ripple)
- Output configuration: NPN NO (Normally Open)/NC (Normally Closed) selectable
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +70℃
- Protection class: IP67 (IEC standard)
- Response frequency: 1kHz
- Cable length: 2m standard (UL2464 PVC shielded cable)
- Weight: 85g ±3%
- Dimensions: 30mm(L) × 16mm(W) × 34mm(H)
- Indicator: Red LED status display
- Hysteresis: ≤15% of sensing distance
High-precision industrial proximity sensor featuring temperature compensation circuitry and reverse polarity protection. The DS1U030's embedded design allows flush mounting in metal surfaces while maintaining stable detection of ferrous targets. Enhanced EMI/RFI shielding ensures reliable operation near VFDs and welding equipment.
- Robotic arm end effector position verification
- Conveyor system object presence detection
- CNC machine tool limit sensing
- Hydraulic cylinder piston position feedback
- Food processing equipment metal contamination detection
Installation guidance:
Maintain 2× sensor diameter clearance between adjacent units. For optimal performance,
conduct final distance adjustment with target material at operating temperature.
Avoid mounting near high-frequency
electromagnetic sources (>50kV/m). For non-ferrous metal detection, specify DS1U-A
series with aluminum sensing capability.
| Property | Property Value |
|---|---|
| sku | DS1U030 |
