Airtac DS1U Electronic Sensor DS1U050
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U050 Electronic Proximity Sensor Technical Details
- Model: DS1U050
- Type: DC 3-wire NPN/PNP switchable inductive sensor
- Sensing distance: 5mm ±10% (adjustable via potentiometer)
- Supply voltage: 10-30V DC (ripple ≤10%)
- Output current: ≤200mA (short-circuit protected)
- Housing material: Nickel-plated brass with PBT sensing face
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Protection rating: IP67 (IEC 60529)
- Response time: ≤1ms (high-speed detection)
- Connection: 2m PUR cable (M8 x 1 connector optional)
- Hysteresis: ≤15% of sensing distance
- Weight: 85g ±3g
- Dimensions: 18mm(D) × 34mm(L) × 10mm(W)
High-frequency oscillation type sensor with LED status indicator (orange=power, green=activation). Features reverse polarity protection and overload current limitation. The corrosion-resistant nickel-plated brass housing withstands industrial coolant splashes. Precision Schmitt trigger circuitry ensures stable detection of metal targets including iron, aluminum, and stainless steel (reduction factor 1 for steel).
- CNC machine tool position verification
- Robotic arm end effector positioning
- Conveyor belt object counting systems
- Hydraulic cylinder piston position feedback
- Automotive assembly line component presence detection
Installation guidelines:
Maintain 2x sensor diameter clearance from adjacent metal surfaces.
For best performance in high-vibration environments, use M5 mounting bolts
with 0.4-0.6Nm torque. Clean sensing face weekly with isopropyl alcohol
in dusty environments.
| Property | Property Value |
|---|---|
| sku | DS1U050 |
