Airtac DS1U Electronic Sensor DS1UN020
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Electronic Sensor DS1UN020 Technical Specifications
- Model: DS1UN020
- Type: Inductive proximity sensor (shielded)
- Sensing distance: 2mm ±10%
- Operating voltage: 10-30V DC (±10% ripple)
- Output configuration: NPN normally open (NO) / PNP optional
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (IEC standard)
- Temperature range: -25℃ to +70℃ (operation), -40℃ to +85℃ (storage)
- Housing material: Nickel-plated brass with PBT sensing face
- Cable length: 2m standard (customizable 1-5m options)
- Connection type: M12 4-pin quick disconnect
- Weight: 68g ±3g
- Dimensions: 18mm(D) × 34mm(L) × 8mm(W)
High-precision industrial-grade proximity sensor featuring temperature compensation circuitry and reverse polarity protection. The tri-color status LED (green=power, orange=adjustment mode, red=output active) enables quick diagnostics. Enhanced EMI/RFI shielding makes it suitable for use near VFDs and welding equipment.
- Position verification in CNC tool changers
- Sheet metal detection in stamping presses
- End-of-stroke detection in pneumatic cylinders
- Rotary encoder synchronization in packaging lines
- Safety interlock systems for machinery guards
Installation guidance:
Maintain 3x sensor diameter clearance from adjacent metal surfaces.
For optimal performance: 1) Clean sensing face weekly with isopropyl alcohol,
2) Avoid mounting on vibrating surfaces exceeding 10G acceleration,
3) Use shielded cable when running parallel to power lines.
| Property | Property Value |
|---|---|
| sku | DS1UN020 |
