Airtac DS1U Electronic Sensor DS1UN050
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Electronic Proximity Sensor DS1UN050 Technical Specifications
- Model: DS1UN050
- Type: Inductive proximity sensor (Shielded)
- Sensing distance: 5mm ±10%
- Output configuration: PNP normally open (NO)
- Supply voltage: 10-30V DC
- Current consumption: ≤15mA
- Operating temperature: -25℃ to +70℃
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Cable specification: 2m PUR cable (Ø5.5mm)
- Repeat accuracy: ≤0.1mm
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Weight: 98g ±3g
- Dimensions: 34mm(D) × 10mm(W) × 50mm(H)
- Connection type: M8 3-pin connector
- LED status indicator: Dual-color (Red/Green)
High-precision industrial-grade proximity sensor featuring temperature compensation circuitry for stable detection in variable environments. The corrosion-resistant brass housing with IP67 protection ensures reliable operation in coolant-exposed or dusty conditions. Built-in reverse polarity protection and short-circuit prevention.
- Position verification in CNC tool changers
- End effector detection in robotic assembly lines
- Pallet presence sensing in automated warehouses
- Safety interlock systems for machinery guards
- Fill level monitoring in liquid dispensing systems
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces (minimum 10mm).
For optimal performance, align target perpendicular to sensing face within ±5° tolerance.
Use shielded conduit in high EMI environments.
| Property | Property Value |
|---|---|
| sku | DS1UN050 |
