Airtac DS1U Electronic Sensor DS1UP020
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Inductive Proximity Sensor DS1UP020 Technical Specifications
- Model: DS1UP020
- Sensor type: Shielded inductive proximity sensor (DC 3-wire)
- Detection distance: 2.0mm ±10% (Standard detection target: Fe 12×12×1mm)
- Supply voltage: DC 10-30V (±10% ripple)
- Output configuration: NPN normally open (NO) / PNP selectable via wiring
- Current consumption: ≤15mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass with PBT sensing face
- Temperature range: -25℃ to +70℃ (Operation), -40℃ to +85℃ (Storage)
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Shock resistance: 1000m/s² (3-axes)
- Weight: 32g ±2g
- Dimensions: 18mm(D) × 34mm(L) × 10mm(W)
High-precision non-contact sensor featuring temperature compensation circuitry for stable detection in fluctuating environments. The embedded reverse polarity protection and short-circuit prevention make it ideal for harsh industrial applications. LED status indicator allows real-time monitoring of operational status.
- Position verification in injection molding machines
- Automated conveyor belt object detection
- Robotic arm end effector alignment
- CNC machine tool limit sensing
- Packaging equipment component counting
Installation guidelines:
Maintain ≥2x sensor diameter clearance from adjacent metal surfaces.
For optimal performance, use M12×1 mounting nut with 0.5-1.5N·m torque.
Avoid copper/aluminum particle contamination in sensing area.
| Property | Property Value |
|---|---|
| sku | DS1UP020 |
