Airtac EAV Standard Pneumatic Control Valve EAV630E
2、Mounting interface compliant with ISO 55991 international standard;
3、Specialized sealing components enable high flow capacity and extended service life;
4、Externally independent pilot air control for non-electrical environments;
5、Requires valve base compatible with ESV solenoid valves, available in single-unit and multi-station configurations - modular multi-station base allows flexible assembly into any required number of positions;
6、Versatile port configurations and mounting options for enhanced adaptability;
7、Series 200/300/400 bases feature integrated exhaust throttle functionality, eliminating external flow control valves;
8、Dual-air pilot models with independent external control operate effectively at zero pressure or vacuum conditions.
Category: Pneumatic Control Valves | Brand: AirTAC | Series: EAV
AirTAC EAV630E Standard Pneumatic Valve Technical Details
- Model: EAV630E (ISO 15407-1 compliant)
- Type: 5/2-way pneumatic control valve with spring return
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (solenoid version)
- Weight: 1.45 kg (3.2 lbs) with manifold base
- Dimensions: 120mm(L) × 50mm(W) × 80mm(H)
- Seal materials: NBR standard (FKM/Viton® optional)
- Temperature tolerance: -20℃ to 80℃ (-4°F to 176°F)
- Flow capacity: Cv 1.2 (Kv 1.05) at 0.6 MPa
- Response time: ≤15ms (at rated pressure)
- Manual override: Built-in emergency actuation button
- Protection class: IP67 (solenoid) / IP40 (valve body)
High-flow directional control valve engineered for industrial automation systems requiring rapid cycling and precise actuator control. Features corrosion-resistant aluminum alloy body with hard-anodized treatment and dust-tight plunger design. Compatible with ISO 15407-1 mounting interfaces for modular system integration.
- Plastic injection molding machine clamp control
- Automotive assembly line robotic actuators
- CNC machine tool chuck operation systems
- Paper converting equipment pneumatic circuits
- Foundry air cylinder sequencing controls
Installation guidelines:
Use 5-7Nm torque for port connections. Install downstream of 25μm filter regulator.
For horizontal mounting, orient exhaust ports downward. Lubricate spool monthly in
high-cycle applications (>500,000 cycles/day).
| Property | Property Value |
|---|---|
| sku | EAV630E |
| Pneumatic Control Type | Three-position double air-piloted center exhaust type |
