Airtac ESV Solenoid Valve ESV230CBI
2. Connection interface mounting dimensions comply with ISO 5599-1 international standard;
3. Equipped with custom-engineered sealing components for enhanced flow capacity and extended service life;
4. Series 200/300/400 enable seamless conversion between internal pilot-operated, external pilot-operated, and pneumatically controlled configurations by adjusting the orientation of sealing components;
5. Base-mounted valve body design with options for single-unit or modular multi-unit bases, allowing flexible assembly into any required number of connected units;
6. Versatile base configurations with multiple air supply connections and mounting options for optimized usability;
7. Integrated exhaust throttling in Series 200/300/400 bases eliminates the need for external throttle valves.
Category: Solenoid Valves, Brand: AIRTAC, Series: ESV
AirTAC ESV230CBI Solenoid Valve Technical Specifications
- Model: ESV230CBI
- Type: 5/3-way double solenoid operated (closed center)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 350g ±5% (including coil)
- Dimensions: 60mm(L) × 42mm(W) × 75mm(H)
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature tolerance: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Flow coefficient (Cv): 1.8
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
- Compatible fluids: Clean compressed air (ISO8573-1:2010 Class 3.4.3)
High-flow proportional control valve featuring dual coil redundancy and position feedback capability. The anodized aluminum body with stainless steel core ensures corrosion resistance in humid environments. Designed for precision mid-stroke control applications requiring stable pressure maintenance between cycles. Requires 5μm filtration and automatic drain installation for optimal performance.
- Robotic arm end-effector positioning systems
- Plastic injection molding machine clamp control
- CNC pneumatic tool changers
- Beverage filling line pressure regulation
- Lithium battery production vacuum/pressure systems
Maintenance protocol:
Perform quarterly lubrication of sliding parts with ISO VG32 turbine oil.
Avoid parallel installation with high-frequency inverters (maintain ≥30cm distance).
| Property | Property Value |
|---|---|
| sku | ESV230CBI |
| Standard Voltage | AC 110V |
