Airtac F-HGS Sensor Mount F-HGS12X15H
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS12X15H Sensor Mounting Bracket Technical Details
- Model: F-HGS12X15H
- Series: HGS compact sensor bracket series
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized (MIL-A-8625 Type II)
- Mounting hole spacing: 12±0.1mm (horizontal adjustment range)
- Vertical height: 15±0.2mm (base to sensor centerline)
- Slot width: 8mm (for M4 mounting bolts)
- Thread specifications: M4×0.7 (sensor mounting threads)
- Weight: 68g ±2g
- Dimensions: 40mm(L) × 20mm(W) × 15mm(H)
- Operating temperature: -40℃ to +120℃
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Corrosion resistance: 96hr salt spray test passed
Precision-machined positioning bracket with micrometer-grade adjustment capability, featuring dual-axis slotted holes for flexible sensor alignment. The hardened anodized surface provides excellent wear resistance against metal shavings and coolant exposure. Compatible with inductive/capacitive sensors up to M12×1 size.
- CNC machine tool limit detection systems
- Automated packaging line position verification
- Robotic end effector collision prevention
- Conveyor belt object presence sensing
- Semiconductor wafer handling equipment
Installation protocol:
Use Class 12.9 steel fasteners with anti-vibration washers.
Apply thread locker on adjustment screws after final alignment.
Maximum recommended torque 1.2N·m for aluminum threads.
| Property | Property Value |
|---|---|
| sku | F-HGS12X15H |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
