Airtac F-HGS Sensor Mount F-HGS12X25H
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS12X25H Sensor Mounting Bracket Technical Details
- Model: F-HGS12X25H
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (black)
- Mounting hole spacing: 25mm ±0.1mm
- Sensor compatibility: F-HG series (HG-2/HG-3/HG-8)
- Thread specifications: M12×1.0 through-hole
- Fastener type: Stainless steel screws (M4×8L, 2pcs included)
- Operating temperature: -40℃ to 85℃
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes)
- Weight: 68g ±2g
- Dimensions: 42mm(W) × 25mm(H) × 32mm(D)
- IP rating: IP67 (when properly installed)
- Torque specification: 0.8-1.2N·m (mounting screws)
Precision-engineered sensor bracket featuring anti-rotation design with dual locking screws. The thermal-stable aluminum construction minimizes positional drift, while the 360° adjustable collar allows flexible sensor orientation. Includes vibration-damping rubber grommets (Shore A 50±5) for shock absorption.
- Position detection in high-speed linear actuators
- Automated packaging line proximity sensor mounting
- CNC machine tool limit switch installation
- AGV collision avoidance system integration
- Food-grade conveyor belt photoelectric sensor fixation
Installation protocol:
Apply thread-locking compound to M4 screws before final tightening.
Use 0.1mm feeler gauge to verify parallel alignment with target surface.
Maximum recommended installation torque: 1.5N·m.
| Property | Property Value |
|---|---|
| sku | F-HGS12X25H |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
