Airtac F-HGS Sensor Mount F-HGS8X15H
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS8X15H Sensor Mounting Bracket Technical Details
- Model: F-HGS8X15H
- Type: Adjustable proximity sensor holder
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized (MIL-A-8625 Type II)
- Mounting hole spacing: 8mm (M4 threaded)
- Adjustment range: ±3° tilt compensation
- Clamping force: 15N·m (max)
- Weight: 82g ±2g
- Dimensions: 34mm(W) × 22mm(D) × 15mm(H)
- Compatible sensors: 12-24mm cylindrical sensors
- Operating temperature: -40℃ to 120℃
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- IP rating: IP67 when paired with sealed sensors
Precision-machined mounting solution for industrial sensors featuring micro-adjustment slots and anti-rotation design. The hardened stainless steel M4 fasteners enable repeated adjustments without thread wear. Thermal-stable construction maintains alignment accuracy in fluctuating temperatures.
- Position verification in CNC tool changers
- Sheet metal detection on stamping press feeders
- Pallet presence sensing in AS/RS warehouses
- End effector alignment for collaborative robots
- Conveyor belt object counting systems
Installation protocol:
Apply 0.5N·m torque during initial mounting. Use shim washers when
securing sensors with diameters below 18mm. Perform alignment verification
after 48 hours of continuous operation.
| Property | Property Value |
|---|---|
| sku | F-HGS8X15H |
| Bore Diameter | <8mm> |
| Stroke | <15mm> |
