Airtac F-TMIC Separate Guide Bracket F-TMICL16X100
$80.92
Regular price
$88.42
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICL16X100
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation note:
Apply M4×8mm flat-head screws with 0.6-0.8Nm torque.
Lubricate with ISO VG32-grade grease annually. Avoid lateral impact
during operation to maintain roller alignment.
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X100 Linear Guide Bracket Specifications
- Model: F-TMICL16X100
- Type: Independent linear guide carriage
- Material: Aluminum alloy base with stainless steel guide rails
- Rail width: 16mm
- Stroke length: 100mm
- Load capacity: Static 1,500N / Dynamic 800N
- Mounting hole spacing: 60mm × 40mm (longitudinal × transverse)
- Precision grade: Normal grade (±0.05mm/m)
- Surface treatment: Hard anodized (black)
- Operating temperature: -20℃ to 120℃
- Weight: 820g ±2%
- Dimensions: 140mm(L) × 32mm(W) × 28mm(H)
- Seal type: Double-lip rubber seals (replaceable)
- Roller material: GCr15 bearing steel (HRC 60-65)
Precision-engineered standalone guide carriage designed for modular linear motion systems. Features hardened steel rails with self-lubricating polymer rollers for smooth travel. Includes alignment pins for accurate multi-unit stacking. Compatible with ISO 10285 standard linear rails.
Typical Applications:
- PCB assembly line conveyor guides
- 3D printer X/Y axis support systems
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling robots
- Medical imaging device sliding mechanisms
Installation note:
Apply M4×8mm flat-head screws with 0.6-0.8Nm torque.
Lubricate with ISO VG32-grade grease annually. Avoid lateral impact
during operation to maintain roller alignment.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X100 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
