Airtac F-TMIC Separate Guide Bracket F-TMICL16X125
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X125 Linear Guide Carrier Specifications
- Model: F-TMICL16X125
- Type: Monolithic linear guide carriage (separate type)
- Rail width: 16mm
- Carriage length: 125mm
- Load capacity (dynamic): 3.2kN (C)
- Load capacity (static): 5.0kN (C0)
- Ball circuit: 4-row circular arc groove design
- Preload level: Medium (Z0)
- Repeat positioning accuracy: ±0.01mm
- Material: Chrome alloy steel (GCR15)
- Surface treatment: Black oxide coating
- Sealing: Triple labyrinth seal with grease retention
- Temperature range: -20℃ to 80℃
- Weight: 0.85kg ±2%
- Dimensions: 125mm(L) × 32mm(W) × 16mm(H)
- Mounting hole pattern: 100mm spacing (M5 threaded)
Precision-engineered linear motion component featuring optimized stress distribution and anti-creep design. The hardened raceways provide exceptional wear resistance, while the enhanced sealing system effectively blocks contaminants in Class 3 cleanliness environments. Requires periodic lubrication with ISO VG32-grade grease.
- High-speed CNC tool changer mechanisms
- Semiconductor wafer handling robots
- Precision optical inspection equipment
- Automated pharmaceutical packaging lines
- 3D printing gantry systems
Installation note:
Apply 0.6-0.8Nm torque during mounting. Use 0.02mm/m precision level
for rail alignment. Break-in period: 50km travel distance at 0.5m/s
before full load operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X125 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
