Airtac F-TMIC Separate Guide Bracket F-TMICL16X150
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X150 Linear Guide Carriage Specifications
- Model: F-TMICL16X150
- Type: Single-axis linear guide carriage (separate type)
- Rail width: 16mm
- Travel length: 150mm ±0.1mm
- Dynamic load capacity: 1,250N
- Static load capacity: 2,850N
- Preload class: C2 (medium preload)
- Material: Carbon steel with black oxide coating
- Seal type: Triple-lip rubber seals with wipers
- Temperature range: -10℃ to 80℃
- Weight: 480g ±2%
- Dimensions: 150mm(L) × 22mm(W) × 24.5mm(H)
- Mounting hole spacing: 60mm × 40mm (longitudinal × transverse)
- Surface hardness: HRC 58-62
Precision-engineered linear motion component featuring hardened steel construction with corrosion-resistant treatment. The triple-seal design incorporates dustproof and anti-contamination barriers, optimized for high-precision repeat positioning (±0.01mm). Requires periodic lubrication with ISO VG15-32 grade grease.
- CNC router Z-axis guidance systems
- Automated optical inspection equipment
- 3D printer gantry alignment mechanisms
- Semiconductor wafer handling robots
- Medical imaging device sliding platforms
Installation notes:
Maintain 0.02mm/m alignment tolerance during rail mounting. Use M4×8mm screws
torqued to 1.6N·m. Clean mounting surfaces with alcohol before assembly to prevent
particulate contamination. Avoid side-loading during operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X150 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
