Airtac F-TMIC Separate Guide Bracket F-TMICL16X200
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X200 Linear Guide Bracket Specifications
- Model: F-TMICL16X200
- Type: Single-axis linear guide support block
- Bore diameter: 16mm
- Stroke length: 200mm
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Hard anodized (25μm)
- Dynamic load capacity: 200N
- Static load capacity: 400N
- Operating temperature: -20℃ to 80℃
- Mounting hole spacing: 30mm (center-to-center)
- Fastener specification: M5×0.8 mounting screws (4 places)
- Weight: 0.82kg ±2%
- Dimensions: 200mm(L) × 50mm(W) × 40mm(H)
- Parallelism tolerance: ≤0.02mm/100mm
- Surface roughness: Ra 0.8μm (guide rail contact area)
Precision-engineered linear motion component designed for smooth guidance in automated systems. Features dual-row ball bearing construction with preloaded clearance (C3 grade), ensuring minimal backlash during reciprocating motion. Includes integrated wiper seals for contamination protection.
- Cartesian robot Z-axis support systems
- CNC tool changer rail guidance
- Automated packaging line pusher mechanisms
- Semiconductor wafer handling equipment
- 3D printer gantry stabilization
Installation note:
Apply lithium-based grease (NLGI #2) to guide rail before assembly.
Tighten mounting screws in cross pattern to 1.2N·m torque.
Avoid side impact during installation.
- Pairs with SHS15/SHS20 linear rails
- Works with AirTAC MDBB15/MDBB20 guide blocks
- Requires 16mm diameter precision shaft (h6 tolerance)
| Property | Property Value |
|---|---|
| sku | F-TMICL16X200 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
