Airtac F-TMIC Separate Guide Bracket F-TMICL16X50
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X50 Linear Guide Bracket Specifications
- Model: F-TMICL16X50
- Type: Single-axis linear guide bracket with integrated bearing
- Material: Aluminum alloy (AL6063-T5) with hard anodized surface
- Bore diameter: 16mm ±0.01mm
- Stroke length: 50mm (effective travel)
- Overall length: 78mm
- Width: 42mm
- Height: 34mm
- Weight: 220g ±5g
- Load capacity: Radial 1,200N / Axial 800N
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-lubricated with Molykote EM-50L grease
- Mounting: Dual M5 threaded holes (pitch 0.8mm) on base
- Surface roughness: Ra 0.8μm (guide rail contact area)
- Repeat positioning accuracy: ±0.02mm
Precision-engineered linear motion component combining guide rail and carriage, featuring low-friction polymer composite bearings. Designed for smooth reciprocating motion in compact installations. Includes integrated dust seals and corrosion-resistant coating for industrial environments.
- 3D printer Z-axis stabilization systems
- CNC router tool head guidance
- Automated test equipment positioning stages
- Medical device linear actuators
- Semiconductor wafer handling robots
Installation note:
Maintain parallel alignment within 0.05mm/m during mounting.
Apply supplemental lubrication every 500km of travel or 6 months
in continuous operation. Avoid side-impact loads exceeding 300N.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X50 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
