Airtac F-TMIC Separate Guide Bracket F-TMICL16X75
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL16X75 Linear Motion Guide Carrier Specifications
- Model: F-TMICL16X75
- Type: Independent guide carriage (separate from rail)
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Bore spacing: 32mm ±0.01mm
- Mounting hole pattern: 16mm × 75mm rectangular array
- Static load capacity: 12.5kN radial / 8.2kN axial
- Dynamic load rating: 6.8kN radial / 4.5kN axial
- Operating temperature: -10℃ to 80℃
- Surface treatment: Black oxide coating (8-12μm)
- Seal type: Triple-lip NBR seals with wiper
- Compatible rail: F-TMIR16 series
- Weight: 350g ±2%
- Dimensions: 75mm(L) × 34mm(W) × 23.5mm(H)
Precision-ground guide carriage featuring 4-row angular contact ball bearings for ultra-smooth linear motion. Engineered for high moment load resistance with optimized recirculation channel design. Includes anti-creep preload adjustment (0.005-0.02mm range) and corrosion-resistant coating for harsh environments. Requires paired with F-TMIR16 series rails.
- High-speed CNC tool changer mechanisms
- Precision optical inspection equipment
- Semiconductor wafer handling robots
- Automated pharmaceutical packaging lines
- Lithium battery electrode stacking machines
Installation note:
Use torque-controlled tightening (2.5-3.0N·m) for mounting screws.
Apply lithium soap-based grease (NLGI #2) during assembly.
Maintain 0.02mm maximum parallelism between paired rails.
| Property | Property Value |
|---|---|
| sku | F-TMICL16X75 |
| Bore Diameter | 16mm |
| Bearing Category | Linear Bearing |
