Airtac F-TMIC Separate Guide Bracket F-TMICL20X100
$102.58
Regular price
$110.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICL20X100
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation note:
Use torque-controlled tightening (1.2N·m max) for mounting screws.
Perform parallel alignment verification with dial indicator (≤0.03mm runout tolerance).
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X100 Linear Guide Carriage Specifications
- Model: F-TMICL20X100
- Type: Monorail linear guide system (single carriage)
- Rail width: 20mm
- Effective stroke length: 100mm
- Material: Aluminum alloy (anodized surface)
- Load capacity: Static 2.1kN / Dynamic 1.4kN
- Precision grade: Normal class (±0.05mm/m)
- Ball diameter: 3.175mm
- Recirculating ball circuit: 4-row design
- Mounting hole pattern: 30mm × 60mm (M4 threaded)
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-packed grease (relubrication interval: 1,000km)
- Weight: 480g ±5%
- Dimensions: 100mm(L) × 34mm(W) × 24.5mm(H)
Precision-engineered linear motion component with hardened steel balls and corrosion-resistant aluminum body. Features integrated sealing strips (IP54 equivalent) to prevent particulate ingress. Requires parallel mounting surface flatness ≤0.02mm for optimal performance.
Typical Applications:
- CNC router Z-axis stabilization systems
- Automated optical inspection equipment
- 3D printer gantry alignment
- Semiconductor wafer handling robots
- Medical linear actuator assemblies
Installation note:
Use torque-controlled tightening (1.2N·m max) for mounting screws.
Perform parallel alignment verification with dial indicator (≤0.03mm runout tolerance).
| Property | Property Value |
|---|---|
| sku | F-TMICL20X100 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
