Airtac F-TMIC Separate Guide Bracket F-TMICL20X125
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X125 Linear Guide Bracket Specifications
- Model: F-TMICL20X125
- Type: Single-axis linear guide bracket with integrated rail
- Material: Aluminum alloy (AL6063-T5) with hard anodized finish
- Bore diameter: Ø20mm (±0.01mm precision ground)
- Stroke length: 125mm (effective travel)
- Dynamic load capacity: 1,200N (radial), 600N (axial)
- Static load capacity: 2,400N (radial), 1,200N (axial)
- Mounting style: Through-hole M5×0.8 mounting screws (4 points)
- Operating temperature: -10℃ to 80℃
- Surface hardness: HV400±50 (anodized layer)
- Weight: 850g ±2%
- Dimensions: 200mm(L) × 42mm(W) × 34mm(H)
- Wear resistance: ≤0.01mm/100km (under standard load)
- Sealing: Integrated dust-proof rubber seals (NBR material)
- Parallelism: ≤0.02mm/100mm
Precision-engineered linear motion solution featuring dual-row ball bearing design for smooth operation and minimal friction loss. The hardened stainless steel rail (SUJ2 material) and optimized preload adjustment ensure vibration-free movement, making it ideal for repetitive high-accuracy applications. Compatible with ISO 10285 standard linear shafts.
- CNC machine tool axis stabilization systems
- Automated optical inspection (AOI) equipment
- 3D printer Z-axis guidance mechanisms
- Semiconductor wafer handling robots
- Packaging machine vertical lift assemblies
Installation note:
Apply lithium-based grease (NLGI #2) to rail surface before assembly.
Use 0.02mm feeler gauge to verify parallel alignment during mounting.
Torque mounting screws to 3.5N·m in crisscross pattern.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X125 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
