Airtac F-TMIC Separate Guide Bracket F-TMICL20X150
$105.84
Regular price
$113.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICL20X150
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation note:
Align within 0.05mm/m parallelism tolerance during mounting.
Relubricate every 500km of travel or 6 months (whichever comes first)
using lithium-based grease. Avoid side-impact loads exceeding 300N.
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X150 Linear Guide Bracket Specifications
- Model: F-TMICL20X150
- Type: Single-axis linear guide support block
- Material: Aluminum alloy (A6063-T5)
- Bore diameter: 20mm (±0.01mm precision)
- Effective stroke: 150mm
- Static load capacity: 1,200N (radial)
- Dynamic load capacity: 800N (radial)
- Operating temperature: -10℃ to 80℃
- Mounting style: Through-hole (M6×4 mounting bolts)
- Surface treatment: Hard anodized (25μm thickness)
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Weight: 540g ±2%
- Dimensions: 178mm(L) × 25mm(W) × 34mm(H)
Precision-engineered linear motion component designed for smooth reciprocating movement in compact automation systems. Features integrated dust-resistant wipers and hardened steel guide shafts (HRC58-62) for extended service life. Compatible with ISO 6432 standard cylinders.
Typical Applications:
- PCB assembly pick-and-place mechanisms
- Semiconductor wafer handling robots
- Precision optical lens positioning stages
- Automated test equipment sliding units
- 3D printer Z-axis stabilization systems
Installation note:
Align within 0.05mm/m parallelism tolerance during mounting.
Relubricate every 500km of travel or 6 months (whichever comes first)
using lithium-based grease. Avoid side-impact loads exceeding 300N.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X150 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
