Airtac F-TMIC Separate Guide Bracket F-TMICL20X200
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X200 Linear Guide Carriage Technical Details
- Full model: F-TMIC-L20X200
- Carriage type: Single block linear guide unit
- Rail width: 20mm
- Stroke length: 200mm
- Material: Hardened steel (HRC58-62) with zinc-nickel coating
- Static load capacity: 12.5kN (C0)
- Dynamic load capacity: 6.8kN (C)
- Accuracy grade: Normal (N) / High (H) optional
- Sealing: Triple labyrinth seal + wiper
- Temperature range: -20℃ to 100℃
- Mounting hole pattern: 40mm × 30mm (longitudinal × transverse)
- Repeat positioning accuracy: ±0.005mm
- Preload level: Medium (C2)
- Lubrication: Grease nipple (M6×1)
- Weight: 0.85kg ±2%
- Dimensions: 200mm(L) × 20mm(W) × 25mm(H)
- Protection rating: IP54 standard / IP58 optional
Precision-engineered linear motion component featuring optimized ball recirculation geometry for smooth operation under heavy loads. The hardened steel construction with multi-stage sealing ensures extended service life in contaminated environments. Requires periodic relubrication every 100km travel or 6 months.
- High-speed CNC router Z-axis mechanisms
- Automated optical inspection equipment stages
- Semiconductor wafer handling robots
- Precision mold clamping systems
- Medical CT scanner sliding gantries
Mounting guidance:
Ensure rail parallelism within 0.02mm/m using precision level.
Tighten mounting screws in cross pattern at 4.5Nm torque.
Run-in with 50% load for initial 5km travel.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X200 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
