Airtac F-TMIC Separate Guide Bracket F-TMICL20X25
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X25 Individual Guide Bracket Specifications
- Model: F-TMICL20X25
- Type: Linear Motion Guide Bracket (Independent Type)
- Bore Diameter: 20mm
- Outer Diameter: 25mm
- Material: Aluminum Alloy 6063-T5
- Surface Treatment: Hard Anodized (25-30μm thickness)
- Preload Class: Normal (C0)
- Static Load Capacity: 1,850N
- Dynamic Load Capacity: 1,200N
- Weight: 0.18kg ±2%
- Dimensions: 25mm(W) × 25mm(H) × 40mm(L)
- Mounting Hole Pattern: 4×M4 threaded holes (6mm depth)
- Temperature Range: -20℃ to 100℃
- Seal Material: NBR Rubber (Replaceable)
- Lubrication: Pre-lubricated with Lithium Soap Grease
Precision-machined guide bracket designed for linear motion systems requiring independent alignment capability. Features dual V-shaped raceways with hardened steel balls (φ3.175mm) for smooth reciprocating movement. Includes integrated dust seals and optional lubrication ports (accessory code: LUB-FT25). Compatible with ISO 10285 standard linear shafts.
- 3D printer Z-axis stabilization systems
- CNC router linear carriage assemblies
- Automated test equipment positioning stages
- Semiconductor wafer handling robots
- Medical imaging device sliding mechanisms
Installation note:
Requires parallel alignment tolerance ≤0.01mm/m. Use torque-controlled tightening (1.2N·m max)
with Loctite 243 threadlocker. Break-in period: 50-100 cycles at 50% rated load.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X25 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
