Airtac F-TMIC Separate Guide Bracket F-TMICL20X250
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X250 Individual Guide Unit Specifications
- Model: F-TMICL20X250
- Series: F-TMIC Compact Linear Guide Series
- Guide width: 20mm (rail dimension)
- Effective stroke length: 250mm ±0.5mm
- Load capacity (dynamic): 1,200N radial / 600N lateral
- Precision grade: C3 (high-precision class)
- Material: Aluminum alloy body with hardened steel guide rails
- Surface treatment: Anodized aluminum, HRC58±2 hardened tracks
- Sealing type: Triple labyrinth seal with grease retention
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated with Molykote PG-641
- Weight: 1.25kg ±3%
- Dimensions: 250mm(L) × 20mm(W) × 30mm(H)
- Mounting hole pattern: 4×M4 threaded holes @ 40mm pitch
- Parallelism: ≤0.02mm/100mm
- Repeat positioning accuracy: ±0.005mm
Ultra-compact linear motion guide system designed for precision positioning in space-constrained automation applications. Features hybrid seals that combine dustproof and oil-retention functions, with hardened raceways for extended service life. Includes pre-drilled mounting holes for simplified integration with compatible AirTAC carriage blocks.
- PCB assembly pick-and-place mechanisms
- Medical device linear actuation systems
- Semiconductor wafer handling robots
- Precision optical adjustment stages
- Laboratory automation slide rails
Installation requirements:
Requires mounting surface flatness ≤0.01mm/m and surface roughness Ra1.6μm.
Compatible with AirTAC F-MSL20 series carriages. Relubrication interval:
1,000km travel or 12 months (whichever comes first). Avoid direct coolant exposure.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X250 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
