Airtac F-TMIC Separate Guide Bracket F-TMICL20X50
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X50 Linear Guide Carriage Specifications
- Model: F-TMICL20X50
- Type: Independent linear guide carriage (non-driven unit)
- Rail width: 20mm ±0.01mm
- Carriage length: 50mm ±0.02mm
- Material: Chrome-plated carbon steel (SCM435 equivalent)
- Ball diameter: 3.175mm precision G10 grade
- Preload level: Medium (C2 class)
- Dynamic load capacity: 6.8kN
- Static load capacity: 10.2kN
- Weight: 420g ±5g
- Dimensions: 50mm(L) × 20mm(W) × 19.5mm(H)
- Mounting hole pattern: 40mm × 15mm (M5 threaded holes)
- Operating temperature: -20℃ to 100℃
- Surface hardness: HRC 58-62
- Surface roughness: Ra 0.2μm max
Precision-engineered linear motion component designed for high-accuracy positioning systems. Features four-row angular contact ball recirculation design with optimized preload for minimal vibration transmission. Includes built-in wipers for particle exclusion (IP54 equivalent protection when paired with compatible rail).
- CNC tool changer mechanisms
- Semiconductor wafer handling robots
- Optical inspection equipment stages
- High-speed packaging line actuators
- Medical imaging device sliding systems
Installation note:
Requires torque-controlled tightening (recommended 2.5N·m for M5 screws)
with sequential cross-pattern fastening. Must be paired with F-TMI20 series
rails. Lubricate with ISO VG15-32 grease before initial operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X50 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
