Airtac F-TMIC Separate Guide Bracket F-TMICL20X75
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL20X75 Linear Guide Carriage Specifications
- Model: F-TMICL20X75
- Type: Independent linear guide carriage (non-driven)
- Material: Hardened carbon steel with zinc-nickel coating
- Load capacity:
- Dynamic: 1,200N (radial)
- Static: 2,800N (radial)
- Moment capacity: 85Nm
- Precision grade: C-class (standard accuracy)
- Mounting hole pattern: 20mm × 75mm spacing (M6 threaded)
- Operating temperature: -20℃ to 100℃
- Surface hardness: HRC 58-62
- Weight: 520g ±10g
- Dimensions: 75mm(L) × 20mm(W) × 25mm(H)
- Roller type: 4-row angular contact ball bearing
- Preload level: Medium (ZN2 class)
Self-contained linear motion unit with integrated recirculating ball system, designed for precision alignment in modular automation setups. Features corrosion-resistant coating and pre-adjusted clearance, enabling direct installation without shimming. Compatible with standard 20mm rail systems.
- Modular robotic arm joints
- 3D printer Z-axis stabilization
- Semiconductor wafer handling systems
- Automated optical inspection stages
- Medical imaging equipment slides
Installation note:
Requires mounting surface flatness ≤0.02mm/m. Apply lithium-based grease
(NLGI #2) to rail before assembly. Use torque-controlled tightening
(4.5-5.5Nm for M6 screws) in cross pattern sequence.
| Property | Property Value |
|---|---|
| sku | F-TMICL20X75 |
| Bore Diameter | <20mm> |
| Bearing Category | Linear Bearing |
