Airtac F-TMIC Separate Guide Bracket F-TMICL25X100
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X100 Linear Guide Carriage Specifications
- Model: F-TMICL25X100
- Type: Monolithic linear guide carriage (separate type)
- Ball circuit: 4-row circular arc groove design
- Rail width: 25mm
- Carriage length: 100mm
- Dynamic load capacity: 12.5kN
- Static load capacity: 23.4kN
- Preload grade: Normal (C0) / Medium (C1)
- Accuracy class: High precision (P5)
- Sealing type: Triple labyrinth seal with stainless steel scrapers
- Material: Chrome-molybdenum alloy steel (SCM435)
- Surface treatment: Black oxide coating + anti-corrosion oil
- Operating temperature: -20℃ to 80℃
- Weight: 0.78kg ±2%
- Dimensions: 100mm(L) × 34.5mm(W) × 39mm(H)
- Mounting hole pattern: 4×M5 threaded holes (depth 8mm)
- Running parallelism: ≤0.005mm/100mm
Precision-engineered linear motion component featuring optimized stress distribution and enhanced moment resistance. The triple-seal design combines non-contact labyrinth seals with positive-contact wipers, effectively blocking contaminants while maintaining smooth motion. Includes pre-drilled mounting holes with counterbores for flush screw installation.
- High-speed CNC tool changer mechanisms
- Semiconductor wafer handling robots
- Precision optical inspection equipment
- Automated pharmaceutical dispensing systems
- 3D printing gantry axis systems
Installation protocol:
Apply Loctite 243 to mounting screws (torque to 3.5N·m).
Perform alignment verification using 0.02mm/m grade straightedge.
Lubricate with ISO VG32-68 grease through 4 zerk fittings before initial operation.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X100 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
