Airtac F-TMIC Separate Guide Bracket F-TMICL25X200
$122.33
Regular price
$129.83
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-TMICL25X200
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. The guide unit-integrated cylinder represents an innovative design combining a guide mechanism with a pneumatic cylinder;
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
Installation requirements:
Apply Loctite 243 to mounting screws (torque 8.8Nm).
Lubricate with ISO VG32 grease before initial operation.
Avoid side-impact loads exceeding 1/3 dynamic rating.
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X200 Linear Guide Bracket Specifications
- Model: F-TMICL25X200
- Type: Single-axis linear guide support block
- Material: Aluminum alloy (A6063-T5) with hard anodized surface
- Compatible rail size: 25mm width
- Effective stroke: 200mm ±0.1mm
- Static load capacity: 12.5kN (radial), 8.2kN (reverse radial)
- Dynamic load rating: 6.8kN (radial), 4.5kN (reverse radial)
- Precision grade: Normal grade (C) with ±0.05mm/m straightness
- Mounting hole pattern: 4×M6×1.0 threaded holes (depth 10mm)
- Surface hardness: HV400±50
- Operating temperature: -20℃ to 80℃
- Protection level: IP54 (standard seals)
- Weight: 1.85kg ±2%
- Dimensions: 250mm(L) × 62mm(W) × 38mm(H)
Precision-machined linear motion component designed for high-rigidity applications. Features integrated wiper seals and grease retention grooves for maintenance reduction. The T-slot design allows modular accessory attachment. Requires pairing with AIRTAC SHS/SBR series 25mm rails.
Typical Applications:
- CNC tool changer sliding mechanisms
- Automated optical inspection (AOI) equipment
- 3D printer gantry systems
- Semiconductor wafer handling robots
- Medical imaging device positioning stages
Installation requirements:
Apply Loctite 243 to mounting screws (torque 8.8Nm).
Lubricate with ISO VG32 grease before initial operation.
Avoid side-impact loads exceeding 1/3 dynamic rating.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X200 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
