Airtac F-TMIC Separate Guide Bracket F-TMICL25X25
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X25 Linear Guide Bracket Full Specifications
- Model: F-TMICL25X25
- Type: Independent linear guide unit (non-driven)
- Compatible cylinder bore: Ø25mm
- Material: Aluminum alloy 6063-T5 with hard anodized surface
- Surface treatment: Black oxidation (RAL 9005) or natural silver
- Weight: 185g ±5g
- Dimensions: 25mm(W) × 25mm(H) × 76mm(L)
- Max load capacity: 300N radial / 150N lateral
- Operating temperature: -20℃ to 80℃
- Mounting hole spacing: 40mm longitudinal pitch (M5 threaded)
- Sliding resistance: ≤1.5N (pre-lubricated with Molykote EM-30L)
- Repeat positioning accuracy: ±0.02mm
- Sealing: Integrated dust wiper (PU material)
- Hardness: HV400 surface hardness
Precision-machined linear motion component designed for guided cylinder applications. Features dual V-groove bearing surfaces with chromium-plated steel shafts (Ø8mm) and adjustable preload mechanism. Includes integrated mounting slots for flexible positioning and anti-vibration rubber pads for noise reduction.
- Precision alignment in SMT component placement machines
- Vertical Z-axis guidance for CNC tool changers
- Linear motion systems in cleanroom automation
- Packaging machine product positioning gates
- 3D printer gantry stabilization
Installation guidelines:
Use 0.02mm feeler gauge to verify parallel alignment during mounting.
Apply lithium-based grease (ISO VG 68) every 500km of travel.
Avoid side-impact loads exceeding 50N·m torque.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X25 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
