Airtac F-TMIC Separate Guide Bracket F-TMICL25X250
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X250 Linear Guide Carrier Unit Specifications
- Model: F-TMICL25X250
- Type: Single-axis linear guide carriage
- Bore diameter: 25mm (precisely honed)
- Stroke length: 250mm (±0.5mm tolerance)
- Material: Aluminum alloy 6063-T5 with hard anodizing
- Surface hardness: HV400-450
- Dynamic load capacity: 1,200N (radial)
- Static load capacity: 2,800N (radial)
- Mounting hole spacing: 60mm × 40mm (M6 threaded)
- Operating temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Weight: 1.85kg (excluding rail)
- Dimensions: 250mm(L) × 42mm(W) × 30mm(H)
- Surface roughness: Ra 0.8μm (sliding surfaces)
- Repeat positioning accuracy: ±0.01mm
Precision-machined linear motion component designed for high-rigidity applications. Features dual-row ball bearing recirculation system with 4-point contact design for smooth motion and minimal deflection. Includes integrated sealing strips (IP54 equivalent) to prevent particulate ingress. Compatible with HGH/SHS series guide rails.
- CNC router Z-axis positioning systems
- Automated optical inspection equipment stages
- Semiconductor wafer handling robots
- High-speed packaging machine linear actuators
- 3D printing gantry systems
Installation note:
Requires parallel alignment within 0.02mm/m using precision level during mounting.
Torque mounting bolts to 5.5-6.0N·m in crisscross pattern. Perform running-in
(20 cycles full stroke) before full-load operation.
- Optimal rail pairing: HGH25CA/SHS25C linear guide
- Recommended end supports: F-MK25 or F-MBP25 series
- Lubrication interval: 500km travel or 6 months (whichever first)
| Property | Property Value |
|---|---|
| sku | F-TMICL25X250 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
